Rotel A14MkII Integrated Amplifier

The Rotel A14MkII Integrated Amplifier offers 80 WPC of Class AB amplification, ready to power your favorite analog, digital, wireless, and USB sources. This amp features a critically tuned power supply, DAC, and amplifier, ensuring reliable performance for years to come. Enjoy your music in high-fidelity with the Rotel A14MkII.

Continuous Power Output - 8 Ohms	80 W/Ch
Maximum Power Output - 4 Ohms	150 W/Ch
Speaker A/B	Yes
Amplifier Class	AB / Custom Designed Toroidal Transformer
Total Harmonic Distortion	< 0.018%
Analog Inputs	4x RCA (Unbalanced) 1x RCA Phono (Unbalanced, MM)
Digital Inputs	2x Optical 2x Coaxial Bluetooth with AptX PC-USB Front USB (iOS Devices Only)
Outputs	1x RCA (Unbalanced) 1x 3.5mm Headphone Jack (Front)
DAC (Digital to Analog Converter)	Texas Instruments 32-bit / 384kHz
Frequency Response - Phono Input	20-20kHz (0 +/- 0.5dB)
Frequency Response - Line Level Inputs	10-100kHz (0 +/- 0.5dB)
Frequency Response - Digital Inputs	10-90kHz (0 +/- 2dB, Max)
Damping Factor	220 (20-20kHz 8 Ohms)
Input Sensitivity / Impedance - Phono Input MM	3.4mV / 47k Ohms
Input Sensitivity / Impedance - Line Level Inputs RCA	230mV / 24k Ohms
Input Sensitivity / Impedance - Digital Inputs	0dBfs / 75 Ohms
Preamp Output / Impedance	1.2V / 470 Ohms
Signal to Noise Ratio - Phono Input (MM)	90dB
Signal to Noise Ratio - Line Level Imputs	100dB
Signal to Noise Ratio - Digital Inputs	103dB
Available Sample Rates - Coaxial / Optical	24-bit / 192kHz
Available Sample Rates - PC-USB	USB Class 1.0 (up to 24-bit 96kHz) USB Class 2.0 (up to 32-bit 384kHz) - Driver Installation Required MQA and MQA Studio (up to 24-bit 384kHz) Roon Tested
Power Consumption - Normal	< 0.5 Watts
Dimensions (WxHxD)	17" x 3 5/8" x 13 1/2"
Panel Height	3 1/8" (80mm)
Weight	19.71lbs (8.94kg)

Price includes shipping to most areas of Canada

Download a spec sheet

Read a review at the Dagogo website.
